TIMKEN JH415647/10

Item Code: Features:
  • Description
  • SKF
  • NSK
  • FAG
  • KOYO

Tapered roller bearing are bearing that can take large axial force

as well as being able to sustain large radial forces.
The inner and outer ring raceways are segments of cones and the

rollers are also made with a taper so that the conical surface of

the raceways and the roller axes if projected, would all meet at a

common point on the main axis of the bearing.
This conical geometry is used as it gives a large contact patch,

which permits greater loads to be carried than with spherical ball

bearings, while the geometry means that the tangential speeds of

the surfaces of each of the rollers are the same as their raceways

along the whole length and no differential scrubbing occurs. When a

roller slides rather than rolls, it can generate wear at the

roller-to-race interface. The difference in surface speeds creates

a scrubbing action. Wear will degenerate the close tolerances

normally held in the bearing and can lead to other problems. Much

closer to pure rolling can be achieved in a tapered roller bearing

and this avoids rapid wear. The rollers are guided by a flange on

the inner ring. This stops the rollers from sliding out at high

speed due to their momentum.
The large the half angles of these cones the large the axial force

that the bearing can sustain.
Tapered roller bearings are separable and have the following

components:outer ring, inner ring, and roller assembly(containing

the rollers and a cage). The non-separable inner ring and roller

assembly is called the cone, and the outer ring is called the cup.

Internal clearance is established during mounting by the axial

position of the cone relative to the cup.

Other Products

Product Name:
Tapered roller bearing 32306
Model:
32306 series
Description:
Structure:Tapered Type:Roller Brand:ASAHI, ,IKO,KOYO, NACHI,NSK,NTN, TIMKEN, Bore Size:15-360mm Outside Diameter:42-480mm Model Number: 32306
Product Name:
NSK HR32217J
Model:

Description:
Product Name:
Tapered roller bearing 32204
Model:
32204 series
Description:
Structure:Tapered Type:Roller Brand:ASAHI, ,IKO,KOYO,LYC,NACHI,NSK,NTN, TIMKEN, Bore Size:15-360mm Outside Diameter:42-480mm Model Number: 32204
Product Name:
Tapered roller bearing 32006
Model:
32006 series
Description:
Structure:Tapered Type:Roller Brand:ASAHI IKO,KOYO, NACHI,NSK,NTN, ,TIMKEN, Bore Size:3-2100mm Outside Diameter:10-1820mm Model Number: 32006
Product Name:
Tapered roller bearing Timken HM803145
Model:
HM803145 series
Description:
Structure:Tapered Type:Roller Brand:ASAHI,FAG,HRB,IKO,KOYO,LYC,NACHI,NSK,NTN,SKF,TIMKEN, Bore Size:15-360mm Outside Diameter:42-480mm Model Number: HM803145
Product Name:
3490/3420 tapered roller bearing
Model:
3490/3420
Description:
1.Competitive price 2.Low noise and vibration 3.High accuracy and long life 4.Small order supported
Product Name:
Tapered roller bearing 501310
Model:
501310 series
Description:
Structure:Tapered Type:Roller Brand:ASAHI, IKO,KOYO,LYC,NACHI,NSK,NTN, TIMKEN, Bore Size:15-360mm Outside Diameter:42-480mm Model Number: 501310
Product Name:
Double row inch tapered roller bearing
Model:
Any
Description:
more
